Allen Bradley PanelView Plus 1500 Keypad to PanelView Plus 7 15" Touch (AP4008-3021-SM)

• Existing HMI:
• Allen Bradley PanelView Plus 1500 Keypad
• Models: 2711P-B15****, 2711P-K15****

• New HMI:
• Allen Bradley PanelView 5000 15" Touch
• Models: 2715-T15CX, 2715P-T15CD
• Allen Bradley PanelView Plus 7 15" Touch
• Models: 2711P-T15C21D8S, 2711P-T15C21D8S-B, 2711P-T15C22A9P, 2711P-T15C22D8S, 2711P-T15C22D8S-B, 2711P-T15C22D9P

• 11 Gauge Heavy Duty Adapter Plate
• Stud Mount Design (Requires Drilling for Studs Around the Existing Cutout)
• Includes a Paper Template for Drilling Around Existing Cutout
• Includes Washers and Lock Nuts for Mounting
• Includes a Seamless Closed-Cell Neoprene Gasket

Download DXF: D014696 AP4008-3021-SM
Download PDF: D014696 AP4008-3021-SM
